HH Wiring Harness with Three-Way Switch

The heart of this drop-in prewired Strat® harness is our custom designed 500K pot. First built over 45 years ago, we wanted the smooth feel and graduated taper found on some vintage 50s guitars. Using a 10-step rotary switch, we created a taper that works with DiMarzio pickups. It’s neither a linear nor audio taper pot -- it's DiMarzio's custom taper. To further increase reliability, we make the center shaft and threaded parts from solid machined brass instead of cheap castings.

This kit also features a premium DiMarzio 3-way Tele®-style switch, a Switchcraft output jack, and both black and white switch tips.

DiMarzio wiring harnesses are all hand assembled and tested in the USA. We use the best sound-tested parts available from Switchcraft®, Sprague®, and CTS®, and we include vintage-style cloth wire.

Ideal for the following switching configuration:


1.     Bridge
2.     Bridge and Neck (parallel)
3.     Neck

Component List:

• 2x DiMarzio Custom Taper Potentiometers – 500K
• Sprague Orange Drop Capacitor - .022uf, 100v
• Gavitt Vintage Hookup Wire – 22 Gauge
• Custom Oak-Grigsby Three-Way Switch
• Switchcraft Output Jack

Fender, Strat and Tele are registered trademarks of Fender Musical Instruments Corp., with which DiMarzio, Inc. is not affiliated.
